• 1．When installing ball valve, the max torque ≤15Nm. If the ball valve is out of operation for a long time, and the torque value of first on or off is the max torque. Or you can choose ball valve with elastic sealing.
• 2. When installing butterfly valve, the max torque≤13Nm. Because the torque value will increased by 10-20% after installing.
• 3．When installing direct mount mode valve, the hole deep ≤15mm. It requires cutting if the output shaft is longer than 15mm.
• 4. Please pay attention to the following items if you install the bracket and coupling by yourself:
• ※ The intensity of bracket should meet the using requirements: the bracket twisting extent ≤0.2mm in the process of on or off.
• ※ The parallelism of bracket ≤0.5mm.
• ※ When processing the shaft hole at both end of the coupling, it is necessary to ensure the accuracy and concentricity. The purpose is to make sure the mechanical hysteresis ≤10°, otherwise it will cause the actuator unable to work.
• 5. Screw should be installed spring washer、flat washer, and we suggest you daub some glue cement around the screw in case of screw loosening.
• 6. After installation, user should switch the valve on and off one time with handle device first. Modifying the valve after make sure it works well


Work environment


• □ This product can be used indoor and outdoor.
• □ This product is not explosion proof, do not use them in flammable and explosive environment.
• □ You need to install protective device for the actuator if it is exposed to the rain or sunshine.
• □ Please pay attention to the ambient temp.
• □ When installing, you need to consider the reserved space for wiring and repairing.
• □ When power on, it is not allowed to dismantle actuator and valve.
• □ When power on, it is not allowed to do wiring.
• □ ※Forbid dropped things hit the device and lead to improper operation.
• □ ※Forbid to step on it which will cause device malfunction or personal accident.
• □ ※It is forbidden to do wiring project in rainy day or when there is water splash.
• □ 02 series is forbid to open the case for wiring,or it will damaged the Sealing performance


• □ In order to use the device safely for a long time,please pre-read the manual carefully to ensure correct use.
• □ Notice item:Please understand the product specification and using method clearly to ensure personal safety or prevent device
• □ In order to indicate damage and danger,here we classify them as “warning ” and “notice ※ ”.
• □ Both of contents are very important,which should be obeyed strictly.
• □ “Warning ”:It will cause death or serious injury if not obeyed.
• □ “Notice ※ ”:It will cause slight injury or device damage if not obeyed.
